Horstmann CentaurStat 7 User Manual

2
The CentaurStat 7 Programmable ThermoStat
The simple instructions contained in this user guide are designed to help with the
programming and operation of the unit.
1 SET indicator
2 SET positions
3 SET button
4 OVERRIDE (MINUS) button
5 OVERRIDE (PLUS) button
6 ENTER button
7 Time or current temperature display
8 Target temperature
9 System ON symbol
10 Day of week indicator
11 PM indicator (no display for AM)
12 Temperature lock symbol
1 10 7
2
9
4
3
5
6
8
12
11
Located under ap

Horstmann CentaurStat 7 Specifications

General

Mounting	Wall-mounted
Temperature Range	5°C to 30°C
Power Supply	230V AC
Frequency	50Hz
Display	LCD
Backlight	Yes
Battery Backup	No
Weight	200g
Type	Programmable Thermostat
Switching Current	3A resistive
Programming	7-day
