10
C. Door Reversal
If you would like to reverse the door hinges, follow the steps below. Otherwise, skip to
section "II.D. Setup."
1) While maintaining a hold on the door, remove the hinge stop pin from hinge (B). Pull
out the bottom of the door slightly and gently remove the door from hinge (A). See
Fig. 1.
) Remove the screws securing the top panel and lift it off. See Fig. .
3) Remove hinge (A) and the bracket from the right side of the unit and the top brace from
the left side. Fasten hinge (A) and the bracket to the left side and the top brace to the
right side. See Fig. 3.
Top Brace
Hinge (A)
Bracket
Screws
Fig. 1
Fig. 2
Fig. 3
Hinge (A)
Hinge Stop Pin
Hinge (B)
To Next Page
