9
3. KM-1900S_J/3
Single Phase
Model Number KM-1900SAJ KM-1900SWJ KM-1900SRJ
AC Supply Voltage 208-230/60/1 (3 Wire with
Neutral)
208-230/60/1 (3 Wire with
Neutral)
208-230/60/1 (3 Wire with
Neutral)
Compressor 230V 10.6RLA 73LRA 230V 13.3RLA 73LRA 230V 10.1RLA 73LRA
Pump 120V 1.2FLA 60W 120V 1.2FLA 60W 120V 1.2FLA 60W
Fan 115V 1.0FLA 1/15HP
(EACH)
--- --- --- 120V 3A MAX (Fans in URC)
Other 115V 0.3A 115V 0.3A 115V 0.3A
Maximum Fuse Size 30 AMPS 30 AMPS 30 AMPS
Max. HACR Breaker
(USA Only)
30 AMPS 30 AMPS 30 AMPS
Max. Circuit Breaker
(Canada Only)
30 AMPS 30 AMPS 30 AMPS
Minimum Circuit
Ampacity
30 AMPS 30 AMPS 30 AMPS
Design Pressure HI-467PSI LO-230PSI HI-427PSI LO-230PSI HI-467PSI LO-230PSI
Refrigerant 404A 4 LB. 10.1 OZ. 404A 3 LB. 1.4 OZ. 404A
Total Refrigerant Charge with
Hoshizaki Remote Condenser
Unit URC-22F: 21 LB. 7.9 OZ.
Three Phase
Model Number KM-1900SAJ3 KM-1900SWJ3 KM-1900SRJ3
AC Supply Voltage 208-230/60/3 208-230/60/3 208-230/60/3
Compressor 230V 8.4RLA 66LRA 230V 7.8RLA 66LRA 230V 8.0RLA 66LRA
Pump 120V 1.2FLA 60W 120V 1.2FLA 60W 120V 1.2FLA 60W
Fan 115V 1.0FLA 1/15HP
(EACH)
--- --- --- 120V 3A MAX (Fans in URC)
Other 115V 0.3A 115V 0.3A 115V 0.3A
Maximum Fuse Size 20 AMPS 20 AMPS 20 AMPS
Max. HACR Breaker
(USA Only)
20 AMPS 20 AMPS 20 AMPS
Max. Circuit Breaker
(Canada Only)
20 AMPS 20 AMPS 20 AMPS
Minimum Circuit
Ampacity
20 AMPS 20 AMPS 20 AMPS
Design Pressure HI-467PSI LO-230PSI HI-427PSI LO-230PSI HI-467PSI LO-230PSI
Refrigerant 404A 4 LB. 10.1 OZ. 404A 3 LB. 1.4 OZ. 404A
Total Refrigerant Charge with
Hoshizaki Remote Condenser
Unit URC-22F: 21 LB. 7.9 OZ.
