HOTA F6+ - Page 14

Charging
LiPo-6S(4.20V) 43%
00:00:01
CH1
0 mAh
22.83 V
0.0A 0W
3.802V
3.807V
1
4
3.808V
3.801V
2
5
3.801V
3.814V
3
6
Standby
00:00:00
CH2
10
F6+ 4-Channel DC Smart Charger
Charging
Operation
Time
Capacity
charged
Task Status
Output
Current
Total Battery
Voltage
Output
Power
Operation
Time
Cell Voltage
Current
channel
Current
channel
Battery parameters and
Percentage of completion
Operation and Setup
Working parameters Display
Charging Status Simple Operation
1. Connect power supply to the AC or DC port of the charger, wait for the system
to complete the self-checking. connect the battery to the charger in the standby interface;
2. After select the corresponding channel，short press OK key to pop up the“Task Settings”
menu, set the task to“Charge”, adjust the task parameters, and short press OK key to
start the task;
Press △ key or ▽ key during operation can switch the display information in the lower half of the
screen, which are cell voltage、cell internal resistance and run data，the cell voltage and internal
resistance can only be displayed in the mode of balance charging（2 minutes）.
3. When the charge task is executing，short press the OK key to pop up the “Adjust Task”
menu，will adjust the charge current，long press the CH key can stop the current task；
4. Enjoy.
