HOTA F6+ - Page 16

12
F6+ 4-Channel DC Smart Charger
Discharging
Discharging
LiPo-6S(3.60V) 36% 00:00:40
CH1
-5 mAh
22.85V
-0.3A -13W
3.787V
3.789V
1
4
3.792V
3.787V
2
5
3.788V
3.703V
3
6
00:00:00
CH2
Standby
Operation and Setup
Working parameters Display
Operation
Time
Capacity
charged
Task Status
Output
Current
Total Battery
Voltage
Output
Power
Operation
Time
Cell Voltage
Current
channel
Current
channel
Battery parameters and
Percentage of completion
Discharging Status Simple Operation
1. Connect power supply to the AC or DC port of the charger, wait for the system
to complete the self-checking. connect the battery to the charger in the standby interface;
2. After select the corresponding channel，short press OK key to pop up the “Task
Settings”menu, set the task to“Discharge”, adjust the task parameters, and short press
OK key to start the task;
Press △ key or ▽ key during operation can switch the display information in the lower half of the screen，
which are cell voltage and run data，the cell voltage and internal resistance can only be displayed in the
mode of balance charging.
3. When the discharge task is executing，short press the OK key to pop up the
“Adjust Task” menu，will adjust the discharge current，long press the CH key can stop
the current task；
4. Enjoy.
