HOTA F6+ - Page 17

External Discharging
Pb-12S(1.90V) 00:00:45
CH1
-111 mAh
26.79V
-9.1A -245W
00:00:00
CH2
0 pcs
36 C
2.99 mWh
26.79V
Standby
External Discharging
13
F6+ 4-Channel DC Smart Charger
Operation and Setup
Working parameters Display
Operation
Time
Capacity
charged
Task Status
Output
Current
Total Battery
Voltage
Output
Power
Operation
Time
Cell Voltage
Current
channel
Current
channel
Battery parameters and
Percentage of completion
External Discharging status Simple Operation
1. Connect the battery, which is going to discharge ,to the input ends( DC port) of the
charger, and wait for the system to complete its self-checking, then in the standby
interface, connect the high power resistance load to the charger's output ends ;
2. After select the corresponding channel， short press OK key to pop up the“Task
Settings”menu, set the task to“Ext. discharge”, adjust the task parameters, and short
press OK key to start the task;
3. When the Ext. discharge task is executing，short press the OK key to pop up the
“Adjust Task”menu，will adjust the Ext. discharge current，long press the CH key can
stop the current task；
4. Enjoy.
