Overall view
Description of the
appliance
Control panel
***Only in completely built-in models.
* Only available in selected models.
The number and type of wash cycles and options may vary depending on the dishwasher model.
1. Upper rack
2. Upper spray arm
3. Tip-up compartments
4. Rack height adjuster
5. Lower rack
6. Lower spray arm
7. Cutlery basket
8. Washing filter
9. Salt dispenser
10. Detergent and rinse aid dispensers
11. Data plate
12. Control Panel***
Low Salt
indicator light
Low Rinse Aid
indicator light
Half Load Option indicator lights
Multi-functional Tablets Option
button and indicator light (Tabs)
Delayed Start Option
indicator light
Wash-Cycle number
and Remaining Time
indicator
Select Wash
Cycle button
Delayed Start
Option button
Half Load Option button
ON/OFF/RESET
button and
indicator light
