Hotpoint CH60GCIW User Manual

9
PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24
INSTALLATION INSTRUCTIONS
UNPACKING THE COOKER
Unpack the components from inside the grill and oven. Check that the following parts are present:
Grill pan and grid Top oven/grill shelf heat shield
Baking dish Pan supports
Main oven shelves (2) Enamelled burner caps (4)
Top oven/grill shelf (1) Literature
Aluminium burner bodies (4)
LEVELLING
Four skid feet are fitted which can be adjusted up or down to level the cooker.
CONVERSION FOR USE ON BUTANE (G30) OR PROPANE (G31)
Each burner requires the injector to be replaced and bypass screws adjusted or replaced as follows:
1. Remove the loose hotplate burner parts.
2. Using a 7mm socket, replace the hotplate injectors as appropriate (see table on previous page).
3. Re-position the loose burner parts.
4. Remove the enamelled baffle at the front of the grill (2 screws).
5. Remove the screw on the right hand side of the burner and gently slide the burner off the injector.
6. Using a 7mm socket, replace the grill injector as appropriate (see table on previous page).
7. Re-assemble the burner and baffle.
8. Inside the top oven, remove the central screw securing the burner retainer. Slide the retainer to the right slightly
and lift away.
9. Lift the burner assembly and place on the floor of the oven to the right of the burner opening.
10. Using a 7mm socket, replace the oven injector as appropriate (see table on previous page).
11. Re-assemble the oven burner and retainer.
12. Replace the main oven injector following the same procedure as for the top oven.
13. From behind the cooker, remove the screws securing the rear panel and swing the left hand side outwards
(viewed from the rear) to gain access to the main oven flame supervision device.
14. Replace the flame supervision device bypass screw.
15. Re-assemble the rear panel.
16. Carefully pull off the control knobs and timer buttons.
17. Remove the 2 screws securing the underside of the control panel. Slide the control panel to the left slightly to
remove.
18. Remove the 6 screws securing the timer mounting panel. Without completely removing it, manoeuvre the timer
mounting panel to gain access to the thermostat bypass screws.
19. Using a narrow flat bladed screwdriver rotate the bypass screws fully clockwise. The main oven thermostat
bypass screw is located on the body of the thermostat below the spindle, the top oven thermostat bypass
screw is located on the body of the thermostat to the right of the spindle and the hotplate tap bypass screws
are located down the centre of the spindle.
20. Re-assemble the control panel parts.
21. Secure the self-adhesive LPG conversion label over the gas details on the data badge.

Hotpoint CH60GCIW Specifications

General

Control type	Buttons, Rotary
Handle color	Stainless steel
Product type	Freestanding cooker
Product color	White
Built-in display	Yes
Control position	Front
Hob type	Gas
Wok burner	No
Cover material	Steel
Cooking zone 1 power	2000 W
Cooking zone 3 power	3000 W
Number of cooking zones	4 zone(s)
Number of electric cooking zones	0 zone(s)
Oven size	Large
Cleaning type	Catalytic
Oven position	Bottom
Number of ovens	2
Number of shelves	2 shelves
Oven net capacity	76 L
Oven gross capacity	83 L
Energy consumption (conventional)	1.64 kWh
Oven 2 energy consumption (conventional)	1.38 kWh
Oven 2 size	Small
Oven 2 position	Top
Oven 2 net capacity	32 L
Oven 2 number of shelves	1 shelves
Oven timer type	Digital

Weight and Dimensions

Width	600 mm
Height	900 mm
