Tall Cabinet Ventilation
Ventilation Slot required
here if cabinet does not
fit to ceiling - 51mm x 457mm min. area
Ventilation Slot
required
here if the cabinet does no
t
fit to the ceiling
- 51mm x 457mm min.
area
Ventilation Slot
required here
- 51mm x 457mm
min. area
50 mm
Air Gap
50 mm
Air Gap
Fig. 1
