The main parts of your
Double Oven
NEVER line the shelves, floor or sides of the oven or grill with aluminium foil as
overheating and damage may result.
(DQ47I/2, DE47X/2 )
WARNING: DO NOT TOUCH THE GLASS DOORS WHEN THE OVEN IS IN USE AS
THESE AREAS CAN BECOME HOT.
Top Oven
Temperature Control
Main Oven
Temperature Control
Timer
Grill Control
Stay Clean
Liner
High Speed Grill Element
Top Oven Light
(not all models)
Grill Pan, Food support and
Anti-Splash Tray
Top Oven Door
Oven Shelves
Main Oven Door
Rod
Shelf
Inner
Door
Glass
Oven
Light
Oven
Fan
Stay Clean
Liner
Meat pan
MODEL & SERIAL
NUMBER LABEL -
Record the Model No.
and the Serial No.
on back page.
Inner Door
Glass
Top
Oven
Pilot
Light
Grill
Pilot
Light
Main
Oven
Pilot
Light
