Hotpoint LSB 5B019 - Description of the appliance; Overall view; Control panel

8
GB
Overall view
Description of the
appliance
*** Onlyincompletelybuilt-inmodels* Onlyavailableinselectedmodels.
The number and type of wash cycles and options may vary depending on the dishwasher model.
1. Upperrack
2. Uppersprayerarm
3. Tip-up dispensers
4. Rackheightadjuster
5. Lower rack
6. Lower sprayer arm
7. Washingfilter
8. Salt dispenser
9. Detergentdispenser,rinse-aiddispenserand
ActiveOxygendevice*
10. Dataplate
11. Controlpanel***
Control panel
Start/Pause button and
indicator light
Salt indicator
light*
Indicator light Wash
Cycle End and
Delayed Start 9h.
Indicator light Drying
and Delayed Start 6h.
Indicator light Washing
and Delayed Start 3h.
Knob
Wash Cycle Select
Button/Indicator
light* On-Off/
Reset
Rinse-aid
indicator
light*
Door handle
