Hotpoint SDL510 - Appliance Description; Overall View; Control Panel Overview

6
EN
Overall view
1. Upper rack
2. Upper sprayer arm
3. Tip-up compartments
4. Rack height adjuster
5. Lower rack
6. Lower sprayer arm
7. Cutlery basket
8. Washing filter
9. Salt dispenser
10. Detergent and rinse aid dispensers
11. Data plate
12. Control panel
***
***Only in completely built-in models.
* Only available in selected models.
Description of the appliance
Control panel
The number and type of wash cycles and options may vary depending on the dishwasher model.
End and 9h. Delayed
start indicator light
Washing and 3h.
Delayed start
indicator light
Drying and
6h.Delayed start
indicator light
Start/Pause
button and
indicator light
Low salt
indicator light
Low rinse aid
indicator light
Delayed start
button
Multi-functional tablets
button and indicator light
WASH CYCLE SELECT knob
Half load
button and
indicator light
ON/OFF/RESET
button
