DELIVERY ACCESS
First, locate the dimensions of your spa on the following chart. The
dimensions shown are the measurements of the spa in the vertical
position, laid on its side.
Next, contact your dealer to find the height and width added by
the delivery cart which the dealer will use to deliver your new
spa. Use the height of the cart plus the dimension shown as H to
determine the vertical clearance required to pass the spa and cart.
Use the width of the cart, or dimension W, whichever is greater,
to determine the maximum width of clearance necessary. Use the
length dimension L when making any sharp turns to determine the
maximum clearance required.
NOTE: It may be necessary to allow for additional over-head
clearance if the spa will be rolled up or down an incline or moved
up or down a short flight of stairs.
Use the information below to determine the requirements for access to your desired location.
x Page x x
How is your width clearance?
Protruding electric meters
A/C units
Do you have sufficient
overhead clearance?
Check low roof eaves,
overhanging branches,
rain gutters
Is the path clear?
Move away branches, dog
houses, firewood, etc.
If there is a 90 turn, can we
clear it? (The spa will not bend)
No more than 6 consecutive
stairs without a landing
Gas meters
Check all gates
HOUSE
BACK YARD
STREET
Page 3 Pre-Delivery Instructions
Model Width W Length L Height H
GRANDEE (GGN) 38" (97 cm) 8'4" (2.54 m) 7'7" (2.31 m)
ENVOY (KKN) 38" (97 cm) 7'9" (2.36 m) 7'7" (2.31 m)
VANGUARD (VVN) 36" (91 cm) 7'3" (2.21 m) 7'3" (2.21 m)
ARIA (ARN) 36" (91 cm) 7'3" (2.21 m) 7'3" (2.21 m)
SOVEREIGN (IIN) 33" (84 cm) 7'9" (2.36 m) 6'8" (2.03 m)
TRIUMPH (TRNH) 33" (84 cm) 7'9" (2.36 m) 6'2" (1.88 m)
PRODIGY (HN) 33" (84 cm) 7'0" (2.13 m) 6'6" (1.98 m)
JETSETTER LX (JTN) 33" (84 cm) 7'0" (2.13 m) 5'5" (1.65 m)
JETSETTER (JJN) 29" (74 cm) 7'0" (2.13 m) 5'5" (1.65 m)
