Hotsy 1200 Series User Manual

28
Parts - 1260SSG, 1270SSG, 1280SSG, 1285SSG 1290SSG
REF PART NO. QTY DESCRIPTION NOTES
1 8.928-377.0 1 WLMT, FRAME ASSY, 1200-SERIES
2 8.706-600.0 1 BOX, BATTERY, M-100
3 9.802-814.0 1 WASHER, 3/8" LOCK
4 9.802-708.0 2 SCREW, 5/16"-18 X 3/4"
5 9.802-832.0 1 BOLT, 5/16" X 2 3/4" WHIZLOCK
6 8.912-129.0 1 STRAP, COIL, HOTSY 1200
7 8.706-547.0 1 GROMMET, 1/2" X 1" X 1/2"
8 9.802-778.0 11 NUT, 5/16" FLANGE, WHIZ LOC
9 8.739-597.0 2 BOLT,FLANGE,8X20MM GX610/620
(1270SSG, 1280SSG,
1290SSG)
NOT SHOWN
- 9.802-065.0 3 GROMMET, 1-5/16" RUBBER
(1270SSG, 1280SSG,
1290SSG)
10 9.802-067.0 7 BUMPER PAD, ENGINE
11 9.802-066.0 7 PAD, SOFT RUBBER, 50 DURO
12 9.802-778.0 2 NUT, 5/16" WHIZ LOC FLANGE
13 8.751-741.0 1 INSULATION PANCAKE, 14"
14 8.706-733.0 2 BUSHING, 1/2" SNAP
15 8.711-785.0 40” HOSE, 3/8" PUSH ON, PER FT
16 8.904-536.0 4 STRAPPING, 1/2" X 48" W/CLAMPS
17 9.802-188.0 1 VALVE, METERING, 1/4" HOSE
18 8.706-547.0 3 GROMMET, 1/2” X 1" X 1/”
19 8.911-328.0 1 LID, 18" OD X 10" ID,WELDMENT
20 8.717-442.0 1
INSULATION, TOP HEAD, 18" OD X 8 ID,
FIBERGLASS
21 8.719-935.0 1 RING, INSULATION RETAINER, 18" TOP HAT
22 8.911-930.0 1 COIL, 18"
23 8.717-446.0 1 INSULATION, BLANKET, FIBERGLASS
24 8.911-331.0 1 WRAP, COIL OUTER ASSEMBLY, HOTSY 1200
25 8.707-019.0 1 HOSE BARB, 1/2" BARB X 3/8" MNPT, BRASS HEX
26 8.911-247.0 1 GUARD, PULLEY BELT
27 8.911-248.0 1 WELDMENT, GEN. BELT GUARD
(1270SSG,
1280SSG,1290SSG)
- 8.911-255.0 1 WELDMENT, GEN. BELT GUARD 1260SSG
(1260SSG, 1285SSG)
28 8.716-610.0 1 GENERATOR, 2FSM2PC-1/A, WINCO
29 8.918-425.0 1 HOSE, 3/8" X 29", 2 WIRE, PRESSURE LOOP
- 8.918-426.0 1 HOSE, 3/8" X 32", 2 WIRE, (SUPER DUTY ONLY)
30 9.802-038.0 1 NIPPLE, 1/2" JIC X 1/2" MPT PIPE
31 8.706-236.0 1 TEE, 1/2" STREET
32 8.706-243.0 1 PLUG, 1/2" SQUARE HEAD, GALVANIZED
33 8.719-000.0 10 WASHER, 5/16" X 1-1/4" FENDER, SAE
34 9.802-756.0 3 BOLT, 5/16" X 1" NC HH, WHIZ LOC
35 8.752-150.0 1 Pc CORD, MOLDED, 14/3 SJEOW
36 8.753-358.0 1 CABLE, BATTERY, 61" EYE TO EYE RED
Hotsy 1200 Operator’s Manual 8.914-366.0 - AL
