Hotsy 1700 Series Operating Instructions And Parts Manual

1700 SERIES PRESSURE WASHER OPERATOR’S MANUAL
23
Hotsy 1700 • 97-6419 • Rev. 7/06
REPAIR KIT NUMBER 70-261 408 70-261 409 70-261 404 70-26 0028 70-260826
KIT DESCRIPTION
*Plunger Seal
15mm
**Complete Seal
Packing
Plunger
15mm Complete Valve Plunger Oil Seals
ITEM NUMBERS
INCLUDED
3, 5, 6
2, 3, 4, 5,
6, 7
34, 35, 36,
37, 38
11, 12, 13 2
NUMBER OF CYLINDERS
KIT WILL SERVICE
3 1 1 6 3
PARTS LIST (CONT.)
5-1206 HD 3030H
ITEM PART NO. DESCRIPTION QTY
33 70-000110 Crankshaft Seal 1
34* 70-030211 Plunger Nut 3
35* 70-120023 Plunger, 15mm 3
36* 70-140027 Copper Spacer 3
37* 70-060130 O-Ring Ø1.78 x 5.28 3
38* 70-000913 Teflon Ring 3
39* 70-000320 Plunger Rod 3
40 70-150204 Connecting Rod Pin 3
41 70-010008 Connecting Rod 3
42 70-140102 Spring Washer 6
43 70-180132 Connecting Rod Screw 6
44 70-070005 Sight Glass 1
45 70-060302 Gasket 1
46 70-020352 Crankcase Cover 1
47 70-060104 O-Ring Ø2.62 x 107.62
* Available in kit (See below)
