1700 SERIES PRESSURE WASHER OPERATOR’S MANUAL
25
Hotsy 1700 • 97-6419 • Rev. 7/06
ITEM PART NO. DESCRIPTION QTY
43 817630 Valve Cage 6
44 945433 Valve Spring 6
45 915310 Valve Plate 6
46 936462 Valve Seat 6
47 926657 Valve Seat "O" Ring 6
48 735317 Hex Screw 8
49 780561 Washer 8
50
51
52 944783 Shim 2
53 780562 Mounting Bolt Washer 8
54 612694 Mounting Bolt 4
55 612691 Plunger Assy Bolt 3
56 926655 Plunger Bolt "O" Ring 3
57 944779 Copper Spacer 3
58 941764 Ceramic Plunger Sleeve (20 mm) 3
59 944782 Copper Spacer 3
60 926685 Teflon Ring 3
61 926692 Connecting-Rod-Pin Snap Ring 6
62 914139 Connecting Rod Pin 3
KIT NUMBER KIT DESCRIPTION
QTY. /
PUMP
877654 Seal Packing Kit (20 mm)
Consisting of:
3 Pressure Ring "O" Rings (926658)
6 "V" Sleeves (941763)
6 Support Rings (926677)
3 Teflon Rings (926681)
1
877645 Complete Seal Packing Kit (20 mm)
Consisting of:
1 Plunger Seal (926653)
1 Pressure Ring "O" Ring (926658)
1 Pressure Ring (926689)
2 "V" Sleeves (941763)
2 Support Rings (926677)
1 Intermediate Ring (926676)
1 Teflong Ring (926657)
3
877648 Complete Valve Assembly Kit
Consisting of:
1 Valve Cage (817630)
1 Valve Spring (945433)
1 Valve Plate (915310)
1 Valve Seat (936462)
1 Valve Seat "O" Ring (926657)
6
877655 Plunger Seal Kit
Consisting of:
3 Plunger Seals (926653)
1
877656 Ceramic Sleeve Kit (20 mm)
Consisting of:
1 Plunger Assembly Bolt (612691)
1 Plunger Bolt "O" Ring (926655)
1 Copper Spacer (944779)
1 Copper Spacer (944782)
1 Ceramic Plunger Sleeve (941764)
1 Teflon Ring (926685)
3
