Hotsy 1700 Series User Manual

21Hotsy 1700 Operator’s Manual 8.914-380.0 - W
Exploded View Parts List
REF PART NO. QTY DESCRIPTION NOTES
24 9.802-131.0 2 ELBOW, 1/2” JIC X 1/2”, 90°
25 9.802-039.0 1
ELBOW, 1/2” JIC X 3/8” STEEL (1710, 1720, 1722, 1723, 1724,
1725, 1743, 1744, 1745)
- 9.802-040.0 1 ELBOW, 1/2” JIC X 1/2”, 90° (1753, 1754, 1755)
26 9.802-129.0 1 ELBOW, 1/2” X JI1C X 3/8”, BRASS
27 8.706-925.0 1 BUSHING, 3/4” X 1/2” PIPE BRASS (1753, 1754, 1755)
28 8.911-329.0 1 COVER, HOTSY 1700 SERIES
- 8.911-330.0 1
COVER, CABINET COLD WATER, 1700, STAINLESS (SS
OPTION)
29 8.911-326.0 1 BASE, HOTSY 1700 SERIES
- 9.802-876.0 1 BASE, RHINO CE, (SS OPTION)
30 9.802-451.0 1 SWITCH, ROCKER, CARLING W/GREEN LENS
- 9.802-452.0 1 SWITCH, ROCKER, RED FACE (TIME DELAY ONLY)
31 9.802-066.0 4 PAD, SOFT RUBBER, 50 DURO
32 9.802-064.0 4 GROMMET, RUBBER, NOZ. HOLDER
33 9.802-146.0 1 SWIVEL, 1/2” MP X 3/4” GHF W/STRAINER
34 8.707-000.0 1 CONNECTOR, 1/2” ANCHOR
35 8.755-033.0 1 BULKHEAD, 3/8" FXF NPT, STEEL
36 9.802-225.0 1 DOWNSTREAM INJECTOR ASSY., NON ADJ #3
37 9.802-171.0 1 NIPPLE, 3/8" X 3/8" NPT ST MALE
38 8.712-357.0 1
NOZZLE, SAQCMEG 00055 RED (1710, 1743,
1744,1745,1725) 1720,1722,1723,1724
- 9.802-800.0 1 NOZZLE, SAQCMEG 0007 RED (1753, 1754, 1755)
39 8.712-358.0 1
NOZZLE, SAQCMEG 15055 YELLOW (1710, 1743, 1744,
1745, 1725) 1720, 1722, 1723, 1724
- 8.712-370.0 1 NOZZLE, SAQCMEG 1507 YELLOW (1753, 1754, 1755)
40 8.712-359.0 1
NOZZLE, SAQCMEG 25055 GREEN (1710, 1743, 1744, 1745,
1725) 1720, 1722, 1723,1724
41 8.712-360.0 1
NOZZLE, SAQCMEG 40055 WHITE (1710, 1743, 1744, 1745,
1725)1720, 1722, 1723, 1724
- 8.712-372.0 1 NOZZLE, SAQCMEG 4007 WHITE (1753, 1754, 1755)
42 8.900-919.0 1 LABEL, HOTSY, 1700 SERIES
43 8.901-106.0 2 LABEL, HOTSY LOGO STRIPE
44 - - BUSHING, SEE SPECIFICATIONS PAGES
45 - - BUSHING, SEE SPECIFICATIONS PAGES
46 - - PULLEY, SEE SPECIFICATIONS PAGES
47 - - PULLEY, SEE SPECIFICATIONS PAGES
48 - - BELT, SEE SPECIFICATIONS PAGES
49 9.802-048.0 1 SWIVEL, 1/2" JIC FEM, 3/8" MALE
50 8.750-246.0 14 SCREW, 1/4" X 1/2" NC, WHIZ LOC BLK CAD
- 8.751-836.0 14 SCREW, 1/4-20 X 1/2", WHIZ LOC FLANGE SS
51 9.802-817.0 4 WASHER, 3/8” X 1" STEEL
- 9.802-818.0 4 WASHER, 3/8” X 1", (SS OPTION)
