PARAMETER LISTS
Parameter
Description
Unit
Level
Factory setting
fromgen.11-UG(150)
30-UG(15)
30-UG(20)
30-UG(27)
30-UG(35)
30-UG(50)
30-UG(70)
30-UG(90)
30-UG(100)
33 2FL Upward ramp of the fan during operation min
–1
/s OEM 100
34 2FM Downward ramp of the fan during operation min
–1
/s OEM 100
35 2FN Post-venting of the fan after lock-out sec OEM 180
36 2FO
Fan speed after a normal switch-off or after
lock-out/blocking
min
–1
OEM 1200 1000 1300 1100 1100 1200 1200 1300 1700
37 2FR Fan afterrun time after operation or blocking min OEM 3
38 2FU Fan speed at boiler freeze protection min
–1
OEM 1500
39 2GA
Waiting time after opening main gas valve or
activation of heating room fan
min OEM 0
40 2GB
External main gas valve/ heating room fan
available
OEM ON
41 2HA Afterrun heating pump or shut-off valve min HF 5
42 2HD Summer operation (“summer kick”) sec OEM 10
43 2IA
Ignition (0-> Internal, 1-> Internal + External,
2-> External)
OEM 2 0 0 0 0 0 0 0 0
44 2KM
Step modulation (0-> off, 1->increasing, 2->
increasing and decreasing)
HF 1
45 2LA Effect of the fault relay HF 2
46 2NA ADC/4 value at 0 bar OEM 25
47 2NB
ADC/4 value at 6 bar and BIC 960 V.2 OEM 145
ADC/4 value at 10 bar and BIC 960 V.3 OEM 225
48 2IB Extended external ignition time sec OEM 8 1 1 1 1 1 1 1 1
49 2QA Reserve % OEM 70
Adaptations for liquid gas
27 2FF
Fan speed during the rst period of pre-
venting
min
–1
OEM 5500 4300 5800 5100 6100 6300 4900 6100 6100
28 2FG Fan speed at start min
–1
OEM 3300 3500 2500 2500 3000 3000 2500 3000 3000
29 2FH Maximum fan speed min
–1
OEM 5500 4300 5800 5100 6100 6300 4900 6100 6100
30 2FI Minimum fan speed min
–1
OEM 1600 1400 1500 1400 1300 1400 1400 1500 1500
36 2FO
Fan speed after a normal switch-off or after
lock-out/blocking
min
–1
OEM 1600 1400 1500 1400 1300 1400 1400 1500 1700
