3
4 205 503 / 14
OVERVIEW
1.
Overview
BIC 960
Automatic gas ring device
with Bus connection to T
opT
ronic
®
T /
T
opT
ronic
®
E
1........ Gas pressure regulator
2 / 3... Gas valve
4........ Fan
5 / 6... Boiler sensor with two sensor elements
7........ Flue gas sensor (only with UltraGas
®
)
8........ Ionisation electrode (+ ignition)
9........ Ignition electrode (double ignition)
10...... W
ater pressure sensor
1
2
3
P
4
5
6
8
9
T
7
T
10
P
2
4
