Hoval BIC 960 - 11;20;21;30;31;41 - Ug (450-1000)

354 205 503 / 14
PARAMETER LISTS
Parameter Description Unit Level Factory setting fromgen.11-UG(150) 11/20/21/30/41-
UG(125) 11/20/21/30/41-
UG(200) 11/20/21/30/41-
UG(250) 11/20/21/30/41-
UG(300) 11/20/21/30/41-
UG(350) 11/20/21/30/31/41-
UG(400)
1 2AA 32769 Blocking temperature °C OEM 95
2 2AC 32770 Maximum reference value °C BE 80
3 2AD 32771 Switch-off hysteresis above reference value °C OEM 10
4 2AE 32772 Switch-on difference relating to tripping point °C HF 10
5 2AF 32773 Proportional part °C OEM 40
6 2AG 32774 Integral part sec OEM 100
7 2AH 32775 Differential part sec OEM 25
8 2AI 32776 Reference value when bus interruption °C HF 75
9 2AJ 32777 Max. temperature rise at low ow temperature °C/sec OEM 1
10 2AK 32778 Max. temperature rise at high ow temperature °C/sec OEM 0.5
11 2AL 32779 “Low” ow temperature °C OEM 60
12 2AM 32780 “High” ow temperature °C OEM 80
13 2BC 32781 Lock-out ue gas temperature °C OEM 110
14 2BD 32782 Blocking ue gas temperature °C OEM 100
15 2CA 32783 Gas pressure switch attached OEM ON
16 2DA 32784 Water pressure sensor attached OEM ON
17 2DB 32785 Water pressure warning bar OEM 1
18 2DC 32786 Water pressure hysteresis bar OEM 0.2
19 2DD 32787 Blocking pressure min. bar OEM 0.5
20 2DE 32788 Blocking pressure min – hysteresis bar OEM 0.2
21 2DF 32789 Blocking pressure max bar OEM 4.8 4.8 4.8 4.8 4.8 5.8 5.8
22 2DG 32790 Blocking pressure max – hysteresis bar OEM 0.2
23 2DH 32791 Lock-out pressure max bar OEM 5 5 5 5 5 6 6
24 2DI 32792 Max. boiler performance at pressure warning % OEM 50
25 2EC 32793 Ionisation warning µA OEM 3
26 2FA 32794 Number of hall impulses per revolution OEM 3
27 2FF 32795 Fan speed during the rst period of pre-venting min
–1
OEM 5700 4800 3900 4800 5700 5600 3600
28 2FG 32796 Fan speed at start min
–1
OEM 1900 1600 1300 1600 1900 1900 1200
29 2FH 32797 Maximum fan speed min
–1
OEM 5700 4800 3900 4800 5700 5600 3600
30 2FI 32798 Minimum fan speed min
–1
OEM 1200 1100 900 1000 1100 1000 900
31 2FJ 32799 Upward ramp of the fan during venting min
–1
/s OEM 500
32 2FK 32800 Downward ramp of the fan during venting min
–1
/s OEM 200
33 2FL 32801 Upward ramp of the fan during operation min
–1
/s OEM 100
34 2FM 32802 Downward ramp of the fan during operation min
–1
/s OEM 100
13.9 11/20/21/30/31/41 - UG (125-400)
