Hover-1 Fuel - Page 21

17
HOVER-1 FUEL DIAGRAM
HANDLEBAR DIAGRAM
1. Handlebar
2. Bicycle Frame
3. Seat Quick Release
4. Seat
5. Front Wheel
6. Battery Pack
7. Battery Dock
8. Front Brake & Rotor
9. Pedal & Crank
10. Bicycle Chain
11. Kickstand
12. Rear Brake & Rotor
FEATURES/PARTS
1
2
4
3
8
9
10
12
11
5
7
6
1. Front Brake Handle
2. Handlebar Grip
3. Gear Shifter ( L )
4. Gear Display ( L )
5. Controls & Display
6. Rear Brake Handle
7. Gear Display ( R )
8. Gear Shifter ( R )
9. Handlebar Grip
1
53
4
2
6
9
8
7
