PARTS LIST FOR MOWER # HM16H4
SCM# PART # DESCRIPTION
1 HM16GXV57 Honda 2 HP, 4 Cycle Engine--U.S & Euro Certif ied
2 HM 1550 Handle Bracket
3 HM16R-1556A Height Adjustment Spacer 1/2"
3 HM16R-1556B Height Adjustment Spacer 1/4"
4 HM16R-21557 Impeller Flat Washer
5 HM16R-225581 Impeller Retaining Bolt 2 1/4"
5 HM16R-225580 Impeller Retaining Bolt 2 3/4”
5 HM16R-225579 Impeller Retaining Bolt 3 1/4"
6 HM16R-22560N Impeller - Assembly
6a HM16R-225572 Impeller - 12”
6b HM16H-225570 Impeller Hub
6c HM16R-225571 Impeller Cap
7 HM16H-22562 Deck with Logos and Decals
8 HM16H-22565 Engine Mount
9 HM 22569 Handle Mounting Plate
10 HM 22573 Clevis Pin
11 HM 2257 Hair Pin Cotter Key
12 HM 22583 Handle Knob W/Hardware
13 HM 1549 Lower Handle
14 HM16R-22585N Upper Handle (With grip)
15 HM 1582 Handle Grip
16 HM 1601-12 Nylon Blades ( Pkg. Of 12)
17 HM 1602-3 Shoulder Bolts for Nylon Blades (Pkg. Of 3)
18 HM 1603-3 Shoulder Bolts for Stainless Steel Blades (Pkg. Of 3)
19 HM16R-22603 Cutter Disc
20 HM16R-22606N Cutter Disc Assy with Nylon Blades & Bolts
20 HM16R-22606S Cutter Disc Assy with Stainless Steel Blades & Bolts
21 HM 1605-3 Reversible Stainless Steel Blades (Pkg. Of 3)
22 HM16R-1607 Bar Blade (Not Available In The U.S.)
23 HM 1551 Handle Stop
24 HM16R-2175 Woodruff Key
25 HM16R-2172 Bail Arm
26 HM16R-2173 Starter Switch with Wiring Harness
27 HM16R-22613 Cutter Disc for Nylon String
28 HM16R-22613T Cutter Disc Assy. With Nylon String & Fasteners
29 HM 1600 String Attachment Fastener (Pkg. of 3)
30 HM 1615-1 .130" Magnum Gatorline - 1 lb. Donut
30 HM 1615-3 .130" Magnum Gatorline - 3 lb. Donut
ACCESSORIES
HM16R-215584 Impeller "Pull" Bolt
HM16R-21563 4" Lift Kit
HM16R-2172C Bail Arm Upgrade Kit
HM16R-21590 12" Handle Extension Kit (
Long Handle, Starter Switch w/Long
Harness
)
HM16R-2173L Starter Switch with Long Wiring Harness
HM 1549L Lower Handle Long
