Additional installation fittings in packCabinet installation fittings
Kitchen installation manual
*NOTE: Hinge and hinge plate may vary
depending on cabinet type.
Cabinet leg
Fixing bracket
*Hinge and hinge plate
13mm CSK screw
13mm CSK screw
2 Part plastic plinth clip
Metal shelf barrel peg
40mm CSK screw
16mm Flange head screw
Standard metal shelf peg
Suspension bracketDeep wall suspension bracket
13m CSK screw
*Hinge and hinge plate
The fittings shown on these pages are standard fittings that may have been
supplied with the cabinet pack for installation.
Other fittings may be shown in this manual for specific cabinet types. These
will be referenced at the appropriate stages.
NOTE: Wall fixing screws have not been supplied
due to different wall types requiring different fixings.
Wall and base cabinets
