Hoyer Y2E2 - Page 16

16
Motor
Manual
Frame size
Drive end (DE) Non-drive end (NDE)
2-pole 4/6-pole 2-pole 4/6-pole
80 6204-ZZ/C3 6204-2Z/C3
90 6205-2Z/C3 6205-2Z/C3
100 6206-2Z/C3 6206-2Z/C3
112 6306-2Z/C3 6306-2Z/C3
132 6308-2Z/C3 6308-2Z/C3
160 6309-2Z/C3 6309-2Z/C3
180 6311-2Z/C3 6311-2Z/C3
200 6312/C3 6312/C3
225 6312/C3 6313/C3 6312/C3
250 6313/C3 6314/C3 6313/C3
280 6314/C3 6317/C3 6314/C3
315 6317/C3 6319/C3 NU319 6317/C3 6319/C3
355 6319/C3 6322/C3 NU322 6319/C3 6322/C3
Table 4 Standard bearing sizes in IE3 Hoyer motors
Frame size
Drive end (DE) Non-drive end (NDE)
2-pole 4/6-pole 2-pole 4/6-pole
80 6204-ZZ/C3 6203-ZZ/C3
90 6205-ZZ/C3 6204-ZZ/C3
100 6306-ZZ/C3 6205-ZZ/C3
112 6306-ZZ/C3 6205-ZZ/C3
132 6208-ZZ/C3 6206-ZZ/C3
160 6209-ZZ/C3 6209-ZZ/C3
180 6211/C3 6311/C3 6211/C3
200 6212/C3 6312/C3 6212/C3
225 6312/C3 6313/C3 6312/C3
250 6313/C3 6314/C3 6313/C3
280 6314/C3 6317/C3 6314/C3
315 6317/C3 6319/C3 NU319 6317/C3 6319/C3
355 6319/C3 6322/C3 NU322 6319/C3 6322/C3
Table 5 Standard bearing sizes in IE4 Hoyer motors
