Motor

Manual

Permissible radial loads for deep groove ball bearings

Frame

size

Bearing size

Motor info

Speed Frequency Poles 20.000 running hours 40.000 running hours

[RPM] [Hz] X0 [N] Xavg [N]

Xmax

[N]

X0 [N]

Xavg

[N]

Xmax

[N]

80 6204-2Z/C3

HMA3 80 2-4 1500 50 4 990 884 799 786 702 634

HMA3 80 2-2 3000 50 2 786 702 634 624 557 503

HMA3 80 1-2 3000 50 2 786 702 634 624 557 503

90 6205-2Z/C3

HMA3 90L-6 1000 50 6 1284 1155 1049 1019 916 833

HMA3 90S-6 1000 50 6 1263 1114 997 1002 884 791

HMA3 90L-4 1500 50 4 1121 1009 916 890 801 727

HMA3 90S-4 1500 50 4 1103 973 871 876 773 691

HMA3 90L-2 3000 50 2 890 801 727 706 635 577

HMA3 90S-2 3000 50 2 876 773 691 695 613 549

100 6206-2Z/C3

HMA3 100L-6 1000 50 6 1730 1532 1375 1373 1216 1091

HMA3 100L2-4 1500 50 4 1511 1338 1201 1199 1062 953

HMA3 100L1-4 1500 50 4 1511 1338 1201 1199 1062 953

HMA3 100L-2 3000 50 2 1199 1062 953 952 843 757

112 6306-2Z/C3

HMA3 112M-6 1000 50 6 2503 2249 2042 1986 1785 1621

HMA3 112M-4 1500 50 4 2186 1965 1784 1735 1559 1416

HMA3 112M-2 3000 50 2 1735 1559 1416 1377 1238 1124

132 6308-2Z/C3

HMA3 132M2-6 1000 50 6 3581 3146 2805 2842 2497 2226

HMA3 132M1-6 1000 50 6 3581 3146 2805 2842 2497 2226

HMA3 132S-6 1000 50 6 3521 3037 2670 2794 2410 2119

HMA3 132M-4 1500 50 4 3128 2748 2450 2483 2181 1945

HMA3 132S-4 1500 50 4 3076 2653 2332 2441 2106 1851

HMA3 132S2-2 3000 50 2 2441 2106 1851 1938 1671 1469

HMA3 132S1-2 3000 50 2 2441 2106 1851 1938 1671 1469

160

6309-2Z/C3

HMC3 160L-6 1000 50 6 4586 4010 3563 3640 3183 2828

HMC3 160M-6 1000 50 6 4505 3877 3402 3576 3077 2700

HMC3 160L-4 1500 50 4 4006 3503 3112 3180 2780 2470

HMC3 160M-4 1500 50 4 3936 3386 2972 3124 2688 2359

HMC3 160L-2 3000 50 2 3180 2780 2470 2524 2207 1961

HMC3 160M1-2 3000 50 2 3124 2688 2359 2479 2133 1872

6309/C3
