Hoyer Y2E2 - Page 23

23
Motor
Manual
Permissible axial loads for open deep groove ball bearings, horizontal
Frame size Bearing size
20.000 running hours
50 Hz 50 Hz 50 Hz 50 Hz
2-pole 3000[RPM] 4-pole 1500[RPM] 6-pole 1000[RPM] 8-pole 750[RPM]
F (push) F (Pull) F (push) F (Pull) F (push) F (Pull) F (push) F (Pull)
(N) (N) (N) (N)
(N)
(N)
(N)
(N)
Horizontal mounting
80 6204-2Z/C3 930 250 1136 456 1290 610 1416 736
90 6205-2Z/C3 995 295 1221 521 1388 688 1527 827
100 6206-2Z/C3 1272 472 1578 778 1805 1005 1992 1192
112 6306-2Z/C3 1721 781 2160 1220 2485 1545 2753 1813
132 6308-2Z/C3 2342 1182 2960 1800 3418 2258 3796 2636
160
6309-2Z/C3 2921 1681 3728 2488 4326 3086 4819 3579
6309/C3 2921 1681 3728 2488 4326 3086 4819 3579
180
6311-2Z/C3 3684 2364 4745 3425 5531 4211 6179 4859
6311/C3 3684 2364 4745 3425 5531 4211 6179 4859
200
6312-2Z/C3 4141 2801 5360 4020 6262 4922 7006 5666
6312/C3 4141 2801 5360 4020 6262 4922 7006 5666
225
6312/C3 4141 2801 - - - - - -
6313-2Z/C3 - - 6024 4684 7054 5714 7903 6563
6313/C3 - - 6024 4684 7054 5714 7903 6563
250
6313-2Z/C3 4633 3293 - - - - - -
6313/C3 4633 3293 - - - - - -
6314/C3 - - 6803 5403 7978 6578 8945 7545
280
6314/C3 5218 3818 - - - - - -
6317/C3 - - 8278 6578 9708 8008 10886 9186
315
6317/C3 6348 4648 - - - - - -
6319/C3 - - 9360 7140 10948 8728 12256 10036
NU319/C3 Special
355
6319/C3 7217 4997 - - - - - -
6322/C3 - - 11452 8512 13373 10433 14956 12016
NU322/C3 -
400
Please contact Hoyer
Table 9
