Item Component Spare part
number
●
Intel Celeron N3060 processor 929565-xx1
●
Intel Celeron N3060 processor (models with 64 GB eMMC memory) L00745-xx1
(9) Fan 927918-001
Heat sink assembly (includes replacement thermal materials)
(10) For use in models with discrete graphics 927920-001
(11) For use in models with 15 W Intel Core processors and UMA graphics 927919-001
(12) For use in models with 6W Intel Pentium and Celeron processors and UMA graphics 933497-001
(13) System board light-blocking cover 937271-001
(14) RTC battery not spared
(15) Solid-state drive, M.2
512 GB, TLC 763008-013
256 GB, TLC 760615-041
128 GB, TLC 759848-022
256 GB, value 865902-013
128 GB, value 827560-042
(16) Memory module
(DDR4-2400) For use in models with Intel Core processors
●
8-GB 862398-855
●
4 GB 862397-855
●
2 GB 864271-855
(DDR3L-1600) For use in models with Intel Pentium or Celeron processors
●
8-GB 693374-005
●
4 GB 691740-005
(17) USB board
NOTE: The USB board cable is available using spare part number 927914-001.
927925-001
(18) WLAN module
Intel Dual Band Wireless-AC 7265 802.11AC 2x2 WiFi + BT 4.2 Combo Adapter (non-vPro) 901229-855
Realtek RTL8723BE-VB 802.11b/g/n 1x1 Wi-Fi + BT4.0 Combo Adapter 855106-855
Intel Dual Band Wireless-AC 3168 802.11 ac 1x1 WiFi + BT 4.2 Combo Adapter 863934-855
(19) Battery (4 cell, 70 Wh, 4.55 Ah) 920070-855
(20) Hard drive, 7 mm (does not include bracket or cable)
NOTE: The hard drive cable is available using spare part number 927917-001.
1-TB, 5400-rpm 762990-005
500-GB, 5400-rpm 778186-005
Computer major components 19
