c. On the back of the display panel, release the adhesive strip (2) that secures the display panel cable
to the display panel, and then disconnect the cable (3).
NOTE: The display will not be connected to the computer as shown in the following image.
4. To remove the display hinges:
a. Remove the two Phillips broad head PM2.5×3.0 screws (1) and the Phillips PM2.0×2.5 screw (2)
that secures each hinge to the display enclosure.
b. Remove the display hinges (3).
60 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
