Item Component Spare part
number
(1) Display assembly
NOTE: For display assembly subcomponent spare part information, see Display assembly
subcomponents on page 19.
not spared
(2) Top cover/keyboard (includes thermal grease and keyboard connector Mylar)
NOTE: For a detailed list of keyboard country codes, see Top cover/keyboard on page 68.
For use in ghost white models with 8250U/8550U processors without a backlight L20669-xxx
For use in ghost white models with 8300H/8750H processors with a backlight L20670-xxx
For use in ghost white models with 8250U/8550U processors with a backlight L21412-xxx
For use in acid green models with 8300H/8750H processors with a backlight L20671-xxx
For use in ultra violet models with 8300H/8750H processors with a backlight L20672-xxx
(3) Power button board (includes rubber and thermal grease)
NOTE: The power button board cable is available using spare part number L20352-001.
Acid green L20342-001
Ultra violet L20343-001
Ghost white L20344-001
(4) Audio board
NOTE: The audio board cable is available using spare part number L20328-001.
For use in models with 8300H/8750H processors L20326-001
For use in models with 8250U/8550U processors L20327-001
(5) TouchPad board
NOTE: The TouchPad cable is available using spare part number L20332-001.
L20333-001
(6) TouchPad bracket (not illustrated) L20331-001
(7) Hard drive connector/cable L20324-001
(8) Hard drive, 2.5-inch (includes sponge; does not include brackets, connector board, or cable)
NOTE: The hard drive cable is available using spare part number L20324-001.
2-TB, 5400-rpm 912487-857
1-TB, 7200-rpm 766457-858
1-TB, 5400-rpm 762990-006
(9) Hard drive bracket L20325-001
(10) Battery (includes Mylar and sponge)
4 cell 917724-856
3 cell L08855-856
(11) Speakers (include thermal grease) L20345-001
(12) Card reader board
16 Chapter 3 Illustrated parts catalog
