Item Component Spare part number
(2) Left L20312-001
(3) Right L20311-001
(4) Hinge brackets (left and right) L21053-001
(5) Hinges (left and right; includes thermal pad kit and thermal grease) L20316-001
(6) HD camera module (includes microphone rubber) L20771-001
(7) Camera boards
HD camera board L20349-001
IR camera board L20350-001
(8) Camera board cables (for use with the HD camera board and the IR camera board) L20347-001
(9) IR FHD camera module (includes microphone rubber) L20770-001
(10) Raw display panel (includes display panel adhesive kit and display enclosure gaskets)
FHD, SVA L20359-001
FHD, UWVA, 144 Hz L20360-001
FHD, UWVA, 60 Hz L20361-001
UHD L20358-001
(11) Antennas, dual (includes thermal pads and grease) L20346-001
Display cable (includes display panel adhesive)
(12) For use in models with an FHD display and IR FHD camera L20355-001
(12) For use in models with an UHD display and IR FHD camera L20357-001
(13) For use in models with an FHD display and HD camera L20354-001
(13) For use in models with an UHD display and HD camera L20356-001
(14) Display enclosure (includes display panel adhesive):
●
Acid green L20313-001
●
Ghost white L20314-001
●
Ultra violet L20315-001
20 Chapter 3 Illustrated parts catalog
