Description Spare part number
Gray HP 15 models 760963-001
Red HP 15 models 760964-001
White HP 15 models 760965-001
Blue HP 15 models 760966-001
Silver HP 15 models 760967-001
Gray Compaq 15 models 749642-001
Purple HP 15 models 775089-001
Black Compaq 15 models 760962-001
Display hinges (left and right)
Models without a touch screen 749655-001
Models with a touch screen 774166-001
Webcam/microphone module
HD 749654-001
VGA 781623-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 41).
5. Remove the following components:
●
Keyboard (see
Keyboard on page 45)
●
Top cover (see
Top cover on page 53)
To remove the display assembly:
1. Disengage the adhesive and disconnect the display panel cable (1) from the system board.
2. Remove the display panel cable from its routing path (2).
78 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
