HP 16500C Service Manual

HP 16501A Replaceable Parts
Ref.
Des.
HP Part
Number QTY Description
Exchange Assemblies
A4 16500-69500 Power supply assembly (exchange)
External Parts
F1 2110-0010
F1 2110-0395
MP1 16501-00201 1 Front-panel
MP2 16501-00203 1 Rear panel
MP3 0363-0125 4 FRI strip-fingers (top and bottom covers)
MP4 1460-1345 2 Tile stand
MP5 16501-00202 1 Sub-panel
MP7 16500-00603 1 Fan screen (rear)
MP12 16500-01207 1 Fan shroun (rear)
MP13 16500-04102 1 Top cover
MP21 5001-0541 2 Side trim-front frame
MP22 5021-8407 1 Frame-front
MP23 5021-5808 1 Frame-rear
MP24 5021-5837 4 Strut-corner
MP25 5041-8801 2 Feet-front (bottom cover)
MP26 54110-40502 4 Feet-back
MP27 5041-8802 1 Top trim strip-frame
MP28 5041-8822 2 Feet-rear (bottom cover)
MP29 5041-8819 1 Strap handle cap-front
MP30 5041-8820 1 Strap handle cap-rear
MP31 5062-3704 1 Strap handle
MP32 5062-3847 1 Cover-left side (with handle)
MP33 5062-3822 1 Cover-right side (without handle)
MP34 5062-3747 1 Cover-bottom
MP37 8160-0551 6 EMI shielding-braided
W5 8120-1521 1 Power cord-United States (7.5 ft)
Electrical Assemblies
A1 16501-66501 1 Expansion interface board
A3 16500-66501 1 Mother board
A4 0950-1853 1 Power supply assembly
B1 3160-0429 2 Fan-tubeaxial
B2 3160-0429 Fan-tubeaxial
W1 98735-61601 1 Cable assembly-interface
W2 16501-61604 1 Cable assembly-ribbon (mother board to expansion interface board)
W3 16501-61603 1 Cable assembly-LED
W4 16500-61604 1 Cable-fan power
Replaceable Parts
HP 16501A Exploded View and Replaceable Parts
