HP 16501A Service Manual

HP 16500C Replaceable Parts
Ref.
Des.
HP Part
Number QTY Description
Exchange Assemblies
A3 16500-69516 Microprocessor board assembly (exchange)
A6 16500-69500 Power supply (exchange)
A8 2095-0001 Color monitor assembly (exchange)
External Parts
F1 2110-0010 Fuse - 5 amp for 230 Vac operation
F1 2110-0395 Fuse - 10 amp for 115 Vac operation
H6 0515-1384 2 Screw M5 X 0.8 10 MM-LG (side handle)
H8 0515-1444 4 Screw M3.5 X 0.6 25.4MM_LG (back feet)
MP3 0363-0125 4 RFI strip - fingers (top and bottom covers)
MP4 1460-1345 2 Tilt stand
MP13 16500-04102 1 Top cover
MP21 5001-0541 2 Side trim (front frame)
MP25 5041-8801 2 Feet - front (bottom cover)
MP26 54110-40502 4 Feet - back
MP27 5041-8802 1 Top trim strip (frame)
MP28 5041-8822 2 Feet - rear (bottom cover)
MP29 5041-8819 1 Strap handle cap - front
MP30 5041-8820 1 Strap handle cap - rear
MP31 5062-3704 1 Strap handle
MP32 5062-3847 1 Cover - left side (with handle)
MP33 5062-3822 1 Cover - right side (without handle)
MP34 5062-3747 1 Cover - bottom
MP37 8160-0551 6 EMI shielding - braided
W7 8120-1521 1 Power cord - United States (7.5 ft)
W7 8120-1703 1 Power cord (Option 900-UK)
W7 8120-0696 1 Power cord (Option 901-Austl)
W7 8120-1692 1 Power cord (Option 902-Eur)
W7 8120-2296 1 Power cord (Option 906-Swit)
W7 8120-2957 1 Power cord (Option 912-Den)
W7 8120-4600 1 Power cord (Option 917-Africa)
W7 8120-4754 1 Power cord (Option 918-Japan)
01660-84501 1 Accessory pouch
0515-1245 Replacement screw for top and bottom covers
0510-1253 Replacement retaining ring for top and bottom covers
Replaceable Parts
HP 16500C Exploded View and Replaceable Parts
7–5
