HP 16500C Replaceable Parts
Ref.
Des.
HP Part
Number QTY Description
MP24 5021-5837 4 Strut - corner
MP35 54110-01210 1 Bracket - color module rear
MP36 54110-04702 1 Support - color module rear
MP38 16500-04105 1 Cover plate
MP39 16500-00606 1 Shield - flexible disk drive
W1 16500-61601 1 Cable - mother board to front panel
W2 16500-61613 1 Cable - CPU to color module 10/40 pin cable (8" long)
W3 16500-61609 1 Cable - CPU to flexible disk drive (34 cond)
W4 16500-61619 1 Cable - fan power
W5 16500-61605 1 Cable - front panel to color module
W6 16500-61606 1 Cable - power supply to color module
W8 16500-61611 1 Cable - hard drive (40 cond)
W9 16500-61612 1 Cable - hard drive power
W10 16500-61613 1 Cable - CRT 10/40 (10 cond/40 pin, CRT to CPU)
W11 16500-61617 1 Cable - I/O
W12 16500-61621 1 Cable - Target Control
W13 16500-61622 1 Cable - Flexible Disk Drive Power
Front-Panel Assembly Parts
A2 16500-66519 1 Board assembly - front panel
H1 0515-0372 9 MSPH M3 8 SMS10
H10 0535-0106 8 Nut - sheetmetal (clips)
MP1 16500-40203 1 Front panel
MP5 16500-00601 1 Static shield
MP17 16500-42202 1 Touch screen bezel
MP18 16500-47402 1 RPG knob
MP40 16500-94311 1 Front panel label
MP41 16500-47401 2 CRT control knob
MP42 5041-4944 1 Keycap
MP43 16500-44701 1 Switch spacer (power switch)
Miscellaneous
16500-40502 Filler panel
Replaceable Parts
HP 16500C Exploded View and Replaceable Parts
7–8
