1-6 Product Overview
Transmission Media
IEEE 802.3
Ethernet
10Base2 Thin coaxial cable with BNC connector.
IEEE 802.3
Ethernet
10Base-T Four pairs of unshielded twisted-pair
Category 3, 4, or 5 cable with RJ-45
connector.*
IEEE 802.3
Fast Ethernet
100Base-TX Four pairs of unshielded twisted-pair
Category 5 cable with RJ-45 connector
for 10 or 100 Mbps operation.
IEEE 802.5
Token Ring
Shielded twisted-pair cable with 9-pin D-connector
(operating at 4 Mbps or 16 Mbps).
IEEE 802.5
Token Ring
Four pairs of unshielded twisted-pair cable with RJ-45 con-
nector (operating at 4 Mbps or 16 Mbps).
*For 10Base-T, the print server works only with a 10Base-T LAN hub or
concentrator that supports link beat (link test pulse) signals.
