HP 1810 Switch Series
Specifications (continued)
HP 1810-8 v2 Switch (J9800A) HP 1810-24 v2 Switch (J9801A)
Ports
7 RJ-45 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX); Duplex: half or full
1 RJ-45 autosensing 10/100/1000 port (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or
full; 1000BASE-T: full only
Supports a maximum of 7 autosensing 10/100 ports plus 1 autosensing 10/100/1000
ports
22 RJ-45 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX); Duplex: half or full
2 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or
full; 1000BASE-T: full only
2 SFP autosensing 100/1000 ports (IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type
1000BASE-T); Duplex: 100BASE-TX: half or full; 1000BASE-T: full only
Supports a maximum of 22 autosensing 10/100 ports plus 2 autosensing
10/100/1000 ports plus 2 SFP ports
Physical characteristics
7.93(w) x 4.65(d) x 1.73(h) in (20.14 x 20.15 x 4.4 cm) (1U height) 12.99(w) x 6.81(d) x 1.73(h) in (32.99 x 17.3 x 4.4 cm) (1U height)
Weight
0.77 lb (.35 kg) 2.2 lb (1 kg)
Memory and processor
128 MB RAM, 8 MB flash; packet buffer size: 512 KB 128 MB RAM, 8 MB flash; packet buffer size: 512 KB
Mounting
wall, desktop and under table mounting Mounts in an EIA-standard 19 in. telco rack (hardware included), horizontal surface,
wall and under table mounting
Performance
100 Mb Latency
< 3.3 µs (64-byte packets) < 3.4 µs (64-byte packets)
Throughput
up to 2.5 million pps up to 9.2 million pps
Switching capacity
3.4 Gbps 12.4 Gbps
MAC address table size
8000 entries 8000 entries
Environment
Operating temperature
0°F to 40°F (-17.8°C to 4.4°C) 0°F to 40°F (-17.8°C to 4.4°C)
Operating relative humidity
15% to 95% @ 104°F (40°C) 15% to 95% @ 104°F (40°C)
Nonoperating/Storage temperature
-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage relative humidity
15% to 95% @ 140°F (60°C) 15% to 95% @ 140°F (60°C)
Altitude
up to 10,000 ft (3 km) up to 10,000 ft (3 km)
Acoustic
Power: 0 dB no fan Power: 0 dB no fan
Electrical characteristics
Voltage
100-240 VAC 100-127/200-240 VAC
Current
.5 A .4/.3 A
Maximum power rating
4.8 W 22 W
Frequency
50/60 Hz 50/60 Hz
Notes
Maximum power rating and maximum heat dissipation are the worst-case theoretical
maximum numbers provided for planning the infrastructure with fully loaded PoE (if
equipped), 100% traffic, all ports plugged in, and all modules populated.
Maximum power rating and maximum heat dissipation are the worst-case theoretical
maximum numbers provided for planning the infrastructure with fully loaded PoE (if
equipped), 100% traffic, all ports plugged in, and all modules populated.
Safety
UL 60950-1; IEC 60950; EN 60950 UL 60950-1; IEC 60950; EN 60950
Emissions
EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR 47, Part 15) Subpart B Class A;
VCCI V-4
EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR 47, Part 15) Subpart B Class A;
VCCI V-4
Immunity
ESD
IEC 61000-4-2 IEC 61000-4-2
Radiated
IEC 61000-4-3 IEC 61000-4-3
EFT/Burst
IEC 61000-4-4 IEC 61000-4-4
Surge
IEC 61000-4-5 IEC 61000-4-5
Conducted
IEC 61000-4-6 IEC 61000-4-6
Power frequency magnetic field
IEC 61000-4-8 IEC 61000-4-8
Voltage dips and interruptions
IEC 61000-4-11 IEC 61000-4-11
Harmonics
EN 61000-3-2 EN 61000-3-2
Flicker
EN 61000-3-3 EN 61000-3-3
Management
Web browser Web browser
Notes
Use only supported genuine HP mini-GBICs with your switch. Use only supported genuine HP mini-GBICs with your switch.
Services
3-year, 4-hour onsite, 13x5 coverage for hardware (UE256E) 3-year, 4-hour onsite, 13x5 coverage for hardware (U4683E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UE257E) 3-year, 4-hour onsite, 24x7 coverage for hardware (U4835E)
