Exchange (HS813E)
Refer to the HP website at:
www.hp.com/networking/services
for details on
the
service-level descriptions and product numbers. For details about services
and response times in your area, please contact your local HP sales office.
HP 1810-24G v2 Switch
(J9803A)
Ports
24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-
T/100BASE-TX: half or full; 1000BASE-T: full only
2 SFP 100/1000 Mbps ports
Supports a maximum of 24 autosensing 10/100/1000 ports plus 2 SFP ports
Physical characteristics
Dimensions
12.99(w) x 6.81(d) x 1.73(h) in
(32.99 x 17.3 x 4.39 cm) (1U height)
Weight
2.54 lb (1.15 kg)
Memory and processor
128 MB RAM, 8 MB flash; packet buffer size: 512 KB
Mounting
Mounts in an EIA-standard 19 in. telco rack (hardware included), horizontal
surface, wall and under table mounting
Performance
100 Mb Latency
< 3.3µs (64-byte packets)
1000 Mb Latency
< 2.2µs (64-byte packets)
Throughput
up to 38.7 million pps
Switching capacity
52 Gbps
MAC address table size
8000 entries
Environment
Operating temperature
32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C)
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 140°F (60°C)
Altitude
up to 10,000 ft (3 km)
Acoustic
Power: 0 dB no fan
Electrical characteristics
Voltage
100-127/200-240 VAC
Current
0.4/0.3 A
Maximum power rating
22 W
Frequency
50/60 Hz
Notes
Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if equipped),
100% traffic, all ports plugged in, and all modules
populated.
Safety
UL 60950-1; IEC 60950; EN 60950
QuickSpecs
HP 1810 Switch Series
Technical Specifications
DA - 13447 North America — Version 18 — January 17, 2014
Page 10
