HP 2009m User Manual

20" LCD Color Monitor HP 2009M&2009F
25
FB601
JUMPER
1 2
FB602
120R/ 6000mA
1 2
VOL
R608
NC /0R05 1/4W 5%
C602220pF
R603 0R05 1/10W 5%
ROUT+
C609
10uF/10V
MUTE
FB604
120R/ 6000mA
1 2
ROUT-
C615 0.47uF/16V
C606
10uF/10V
FB605
120R/ 6000mA
1 2
C603220pF
LOUT+
A
Custom
14Wednesday , January 07, 2009
OD M MOD EL
01.COVER
G3322-1-X-X-2-090107
OEM MODEL Size
Rev
Date
Sheet
of
TPV MOD EL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
CN601
CONN
1
2
3
C618
0.001uF
+5V1
C612
1uF/25V
R607
3K 1/10W 5%
C619
0.001uF
R602
1K 1/10W 5%
C614 0.47uF/16V
C605220pF
C610
1uF/25V
INL
FB603
120R/6000mA
1 2
MUTE
R604 0R05 1/10W 5%INR
INR
C617
1uF/25V
U601
PAM8603MDET
1
2
3
4
5
6
7
8
9 10
11
12
13
14
15
16
17
18
+OUTL
PGNDL
-OUTL
PVDDL
MU TE
VDD
INL
VDC
VOLUME VR EF
NC
INR
GND
SHDN
PVDDR
-OUTR
PGNDR
+OUTR
LOUT-
INL
R606
3K 1/10W 5%
C620 0.47uF/ 16V
C604220pF
CN 602
CONN
1
2
3
4
+ C601
470uF25V
C607
1uF/25V
C611
27K 1/8W 5%
+5V1
C616
4.7uF/16V
C608
1uF/25V
R601
100R 1/10W 5%
R605
100R 1/ 10W 5%
IC901

HP 2009m Specifications

General

3D	No
Pixel pitch	0.2768 x 0.2768 mm
Aspect ratio	16:9
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1600 x 900
On/off switch	Yes
DVI-I ports quantity	0
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	47 W
Power consumption (standby)	2 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Certification	FCC
Country of origin	China

Weight and Dimensions

Depth (without stand)	289 mm
Width (without stand)	523 mm
Height (without stand)	480 mm
Weight (without stand)	9000 g
