HP 2009m User Manual

20" LCD Color Monitor HP 2009M&2009F
26
7.3 Key Board
POWER
SW001
CN001
CONN
1
2
3
4
5
6
78
UP
SW002
SW
3 4
21
6
5
LED001
SW004
SW
3 4
21
6
5
ZD004 UDZSNP5.6B
POWER
AUTO
PLUS+
SW002
LED_O
OSD KEY LOCATION
ZD001 UDZSNP5.6B
SW003
AUTO
SW003
SW
3 4
21
6
5
MENU
LBADC2
UP
6
AUTO
ZD003 UDZSNP5.6B
SW005
SW
3 4
21
6
5
2009m A
HP 2009m A
22Tuesday , October 07, 2008
715G3309-B
.
02 OSD KEY
G3309-B-X-X-1-080827
OEM MODEL Size
Rev
Date
Sheet
of
TPV MODEL
PCB NAME
备注
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
线路图编号
SW004
LED_G
LBADC1
LBADC1
LED001
LED
1 2
3 4
R004
1K8 1/10W 5%
(1.8K)
(1.8K)
R001
3K 1/10W 5%
ZD002
UDZSNP5.6B
MENU
DOWN
GND
DOWN
CN001
(3.0K)
ZD005 UDZSNP5.6B
SW005
R003
3K 1/10W 5%
MINUS-
GND
LBADC2
R002
1K8 1/10W 5%
(3.0K)
1
SW001
SW
3 4
21
6
5
MENU

HP 2009m Specifications

General

3D	No
Pixel pitch	0.2768 x 0.2768 mm
Aspect ratio	16:9
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1600 x 900
On/off switch	Yes
DVI-I ports quantity	0
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	47 W
Power consumption (standby)	2 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Certification	FCC
Country of origin	China

Weight and Dimensions

Depth (without stand)	289 mm
Width (without stand)	523 mm
Height (without stand)	480 mm
Weight (without stand)	9000 g
