HP 22er User Manual

24-07-201
HP Restricted
Page 2
Step 2: Strip the screws from rear cover, then move rear cover follow the below way ,at last
remove deco
Step 3: To remove the shielding(contain the other material );
(3.1) Dismantle the rear cover supporter
(3.2) Pull out the LVDS/ LED FFCs to separate the base assembly from the unit;
(3.3) Remove the four screws to separate shielding from CB
Remove the screws with
Screwdriver
Dismantle the rear cover first
from the two marked position
Remove the 8pin FFC from main
board then remove rear cover
