HP 22f User Manual

EL-MF877-00 Page 2
Template Revision C
Last revalidation date 04-01-2018
HPI instructions for this template are available at EL-MF877-01
Item Description
Notes
Quantity of
items
included in
product
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
None
Components and waste containing asbestos
None
Components, parts and materials containing refractory
ceramic fibers
None
Components, parts and materials containing
radioactive substances
None
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components and
materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Plastic shovel
Screwdriver
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment
including the required steps to remove the external enclosure:
1. Remove screws from Rear cover and Separate the Rear Cover Ass'y
2. Remove the connector(J2)and(BJ2) of the FCC cable.
3. Remove the connector(J3) of the Dispaly key bd cable.
4. Remove four screws① from Main shielding and Panel.And separate the tapes from the Main shielding.
5. Remove three screws②from MAIN SHIELDING ang Main BD.
6. Remove four screws① from Main shielding and Main BD.Separate the MAIN SHIELDING from Main BD.
7. Separate the MAIN BD.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items contained in the
product that require selective treatment (with descriptions and arrows identifying locations).

HP 22f Specifications

General

3D	No
Pixel pitch	0.247 x 0.247 mm
Screen shape	Flat
Display diagonal	21.5 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	48 - 75 Hz
Horizontal scan range	30 - 86 kHz
Viewable size, vertical	267.8 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Tilt angle range	-5 - 25 °
Product color	Silver
Country of origin	China
Market positioning	Home
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.16 W
Power consumption (standby)	0.23 W
Power consumption (typical)	18 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Silver, ENERGY STAR
Cables included	AC, HDMI
Package depth	132 mm
Package width	568 mm
Package height	387 mm
Package weight	4000 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	180 mm
Width (with stand)	489.6 mm
Height (with stand)	380 mm
Depth (without stand)	39.7 mm
Width (without stand)	489.8 mm
Height (without stand)	296.7 mm
Weight (without stand)	2330 g
