Connecting the Audio Cable
Connect one end of the provided audio cable to the Audio In connector on the rear of the monitor and
the other end to the Audio Out connector on the computer.
NOTE: If you connect an HDMI cable (2310t model only) between the monitor and computer, you
do not need to connect the audio cable. The HDMI cable supports audio and video digital signals.
Figure 3-7 Connecting the Audio Cable
Connecting the USB Cable
Connect one end of the provided USB cable to the USB upstream connector on the rear of the
monitor and the other end to a USB downstream connector on the computer.
NOTE: You must connect the USB cable for touch screen functionality.
Figure 3-8 Connecting the USB Cable
8 Chapter 3 Setting Up the Monitor ENWW
