Removing the Monitor Pedestal Base

You can remove the monitor panel from the pedestal base to mount the panel on a wall, a swing arm,

or other mounting fixture (purchased separately).

CAUTION: Before beginning to disassemble the monitor, be sure the monitor is turned off and the

power and signal cables are both disconnected. Also disconnect the USB and audio cables if they are

connected to the monitor.

1. Disconnect and remove all cables from the back of the monitor.

2. Lay the monitor face down on a flat surface covered by a dry, clean cloth.

3. Pry back the top of the VESA cover plate (1) then slide it up (2) to remove it from the back of the

monitor.

Figure 3-12 Removing the VESA Cover Plate

12 Chapter 3 Setting Up the Monitor ENWW
