Attaching the VESA Mount Kit (Available with Select Models)

1. Remove the monitor stand. Refer to Removing the Monitor Stand on page 13.

2. Remove the screw from the center of the rear of the display head.

3. Insert the tab at the bottom of the VESA mount into the slot on the back of the display head until

the VESA mount clicks in place (1), and then secure the top of the VESA mount with the screw

that was installed in the center of the display head (2).

4. To attach the monitor to a swing arm or other mounting device (purchased separately), insert

four mounting screws through the holes on the mounting device and into the screw holes on the

VESA mount that was installed on the rear of the monitor.

14 Chapter 3 Setting Up the Monitor
