Bottom
Component Description
(1) Battery bay Holds the battery.
(2) Vents (3) Enable airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool internal
components and prevent overheating. It is normal for the internal
fan to cycle on and off during routine operation.
(3)
Battery release latch Releases the battery from the battery bay.
Bottom
27
