Item Component Spare part
number
(1) Display assembly (35.6-cm [14.0-in] HD, anti-glare, touchscreen)
NOTE: For display assembly spare part information, see Display assembly subcomponents on page 22.
(2) Top cover/keyboard (includes touchpad)
NOTE: For a list of country code suxes for the top cover/keyboard spare part numbers listed below,
see Bottom cover on page 34.
For use in all black models (HP Notebook and HP 245 G4 Notebook) 813513-xxx
For use in turbo silver HP Notebook models 813915-xxx
For use in white silver HP Notebook models 813911-xxx
For use in purple HP Notebook models 813913-xxx
For use in blue HP Notebook models 813912-xxx
For use in red HP Notebook models 813914-xxx
(3) Touchpad button board (includes bracket) 813517-001
(4) Power button board (includes cable) 813516-001
(5) Power connector cable 813505-001
(6) System board (includes replacement thermal materials):
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-501: Windows 8.1 Standard operating system
xxxxxx-601: Windows 8.1 Professional or Windows 10 operating system
For use in HP Notebook PC models:
Discrete graphics memory, non-touch screen models:
●
AMD A6-6310 processor and 2 GB of discrete graphics memory
814511-001,
-501
UMA graphics memory, non-touch screen models:
●
AMD A8-7410 processor
814509-001,
-501
●
AMD A6-6310 processor 814508-001,
-501
●
AMD A6-5200 processor 823411-001,
-601
●
AMD A4-5000 processor 823410-001,
-601
●
AMD E1-6015 processor 814506-001,
-501
●
AMD E1-6015 processor and 2 GB of integrated system memory 814507-001,
-501
18 Chapter 3 Illustrated parts catalog
