Speakers
Description Spare part number
Speakers (includes left and right speakers and cable) 925376-001
Before removing the speakers, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 28).
5. Remove the optical drive (see Optical drive on page 29), if installed.
6. Remove the bottom cover (see Bottom cover on page 35).
To remove the speakers:
1. Disconnect the speaker cable from the system board (1).
2. Remove the cable from its routing path along the bottom of the computer (2).
3. Remove the 2 Phillips PM2.5×3.0 screws (3) that secure the speakers to the computer.
50 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
