HP 245 G6 User Manual

106 pages

To Next Page

To Previous Page

d. Remove the display panel from the computer (2).

NOTE: The display will not be connected to the computer as shown in the following image.

4. To remove the display hinges:

a. Pull either side of each hinge cap to disengage it from the enclosure (1).

60 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

Questions and Answers:

Need help?

Do you have a question about the HP 245 G6 and is the answer not in the manual?

General

Operating System	Windows 10 Home
Processor	AMD A6-9220
RAM	4GB DDR4
Storage	500GB HDD
Display	14-inch HD (1366 x 768)
Graphics	AMD Radeon R4
Ports	1 HDMI, 1 RJ-45, 1 headphone/microphone combo
Wireless	Bluetooth 4.2
Battery	3-cell Li-ion (41 Wh)
