Mass storage devices
Item Component Spare part number
(1) Hard drive (2.5-in, SATA; does not include hard drive cable or bracket):
NOTE: The hard drive cable and bracket are included in the Hard Drive Hardware Kit, spare part number 685089-001.
750-GB, 5400-rpm 634250-001
640-GB, 5400-rpm 669300-001
500-GB, 5400-rpm 669299-001
320-GB, 5400-rpm 622643-001
Hard Drive Hardware Kit, includes: 685089-001
(2a) Hard drive bracket
(2b) Hard drive cable
(3) Optical drive (DVD±RW Double-Layer SuperMulti Drive; includes rear optical drive bracket
but does not include optical drive cable or cable bracket)
NOTE: The optical drive cable and cable bracket are included in the optical drive cable kit,
spare part number 685084-001.
689685-001
(4) Optical drive cable (includes cable bracket) 685084-001
Optical drive plastic insert (for use in models without an optical drive; not illustrated) 727614-001
22 Chapter 3 Illustrated parts catalog ENWW
