12
Step 3: To remove the shielding(contain the other material );
(3.1) Remove the acetate tapes covering the LVDS/ LED FFCs;
(3.2) Pull out the LVDS/ LED FFCs to separate the base assembly from the unit;
(3.3) Remove the four screws to separate shielding from CB
(3.4) Dismantle the rear cover supporter
Remove the screws with Screwdriver
Dismantle the rear cover first from
the two marked position
Remove the 8pin FFC from main board
then remove rear cover
Remove all tape and LVDS cable/FFC cable
To Next Page
